Anti Climbing Bto-28 Barbed Wire Cattle Fence Corrugated
| Place of Origin | MADE IN CHINA |
|---|---|
| Brand Name | TALIN |
| Model Number | BTO-10，BTO-15，BTO-18，BTO-22，BTO-28，BTO-30，CBT-60，CBT-65 |
| Minimum Order Quantity | 10000meters |
| Price | FOB USD 5-10 per coil |
| Packaging Details | wooden pallets |
| Delivery Time | 5-8 days |
| Payment Terms | T/T, L/C |
| Supply Ability | 10000M per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Hot Dip Galvanized Wire | Size | BTO-10，BTO-15，BTO-18，BTO-22，BTO-28，BTO-30，CBT-60，CBT-65 |
|---|---|---|---|
| Package | Wooden Pallet | Application | Fence Protection |
| Delivery | 7-8 Days For 10000 Meters | Types | Straight Line Or Concertina Coils |
| High Light | anti climbing barbed wire cattle fence,bto-28 barbed wire cattle fence,corrugated barbed wire farm fence |
||
Product Description
Anti-climbing Easy and Economical BTO-28 Corrugated barbed wire cattle fence
The accordion-type blade barbed wire is made of hot-dip galvanized steel sheet or stainless steel sheet to punch out a sharp blade shape, and high-tensile galvanized steel wire or stainless steel wire is used as a core wire. Due to the unique shape of the gill net, it is not easy to touch, so it can achieve excellent protection and isolation effect.
The accordion type razor barbed wire is two adjacent razor barbed wire staggered and connected together with buckles. After unfolding, it becomes a cross shape, which greatly shortens the gap between the two rings and plays a better protective role. During the installation process The wire needs to be pulled inside the blade barbed wire loop for better stability.
Common specifications and models:
| Blade Size | Style | Thickness | Diameter of center line | Length | Width | Distance |
| BTO-10 |  |
0.5±0.05 | 2.5±0.1 | 10±1 | 13±1 | 26±1 |
| BTO-12 | |
0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 26±1 |
| BTO-18 | |
0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 33±1 |
| BTO-22 | |
0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 34±1 |
| BTO-28 | |
0.5±0.05 | 2.5 | 28 | 15 | 45±1 |
| BTO-30 | |
0.5±0.05 | 2.5 | 30 | 18 | 45±1 |
| CBT-60 | |
0.6±0.05 | 2.5±0.1 | 60±2 | 32±1 | 100±2 |
| CBT-65 | |
0.6±0.05 | 2.5±0.1 | 65±2 | 21±1 | 100±2 |
Features:
The product has excellent deterrent effect, strong anti-climbing ability, beautiful appearance, simple construction, economical and practical and so on.
Application:
It is mainly used for the enclosure protection of garden apartments, government agencies, prison posts, military management areas, border defenses and other places.
