4''x4'' PVC Welded Wire Mesh Low Carbon UV Resistance 1.8m
| Place of Origin | CHINA |
|---|---|
| Brand Name | TALIN |
| Model Number | 1/2*1M*25M*12KG |
| Minimum Order Quantity | 20Ton |
| Price | USD |
| Packaging Details | PLASTIC PACKAGES |
| Payment Terms | L/C, , T/T |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Low Carbon Steel Wire ,PVC Coated | Aperature | 1/4'' ,1/2'' ,3/4'' ,1'' |
|---|---|---|---|
| Wire Dia. Before Coat | 0.56-4mm | Wire Dia. After Coat | 0.9-4.88mm |
| Width | 0.6-1.8m | Length | 10-50m |
| High Light | Low Carbon PVC Welded Wire Mesh,1.8m PVC Welded Wire Mesh,4x4 welded wire mesh |
||
Product Description
PVC WELDED WIRE MESH
PVC welded wire mesh is welded by black wire, galvanized wire and hot deep galvanized wire. The surface of mesh need sulfur treatment. Then painting PVC powder on the mesh. The characters of this kind mesh are strong adhesion, corrosion protection,acid and alkaline resistance, aging resistance, non-fading, UV resistance, smooth surface and bright.
Application: Suitable for fencing houses and properties, companies, gardens recreation areas, parks. All kinds of colors can be coated according to customers' special requirements. PVC coated welded wire mesh is supplied in rolls or panels. Colors can be green, black, white, yellow,red,bule,etc.
| Mesh size | Wire Dia. Before coat | Wire Dia. After coat | Width | Length |
|---|---|---|---|---|
| 1/4"x1/4" | 0.56 - 0.71 | 0.90 - 1.05 | 0.6m - 1.8m | 10 - 50m |
| 3/8"x3/8" | 0.64 - 1.07 | 1.00 - 1.52 | ||
| 1/2"x1/2" | 0.71 - 1.65 | 1.10 - 2.20 | ||
| 5/8"x5/8" | 0.81 - 1.65 | 1.22 - 2.30 | ||
| 3/4"x3/4" | 0.81 - 1.65 | 1.24 - 2.40 | ||
| 1" × 1/2" | 0.81 - 1.65 | 1.24 - 2.42 | ||
| 1"x1" | 0.81 - 2.11 | 1.28 - 2.90 | ||
| 1-1/2"x1-1/2" | 1.07 - 2.11 | 1.57 - 2.92 | ||
| 1"x2" | 1.47 - 2.11 | 2.00 - 2.95 | ||
| 2"x2" | 1.65 - 2.77 | 2.20 - 3.61 | ||
| 3"x3" | 1.90 - 3.50 | 2.50 - 4.36 | ||
| 4"x4" | 2.20 - 4.00 | 2.85 - 4.88 |
